TBR TIRE
FD804
Features:
Four straight grooves improve driving stabllity.
Unique pattern design for uniform pressure distribution and better performance.
The trench in the bottom of the grooves helps to eject the stones and provides longortire life.
Small sipes for better grip performance.
Suitable for:
Suitable for steer and trailer position of truck and all wheel position of bus.
medium and long distance transportation on good paved road and highway.
Description
TYRE SIZE | PLY RATING | LOAD INDEX | SPEED SYMBOL | STANDARD RIM | TREAD DEPTH (mm) | OVERALL DIAMETER (mm) | SECTION WIDTH (mm) | MAX LOAD (single/dual) (kg) | MAX PRESSURE (single/dual) (kpa) |
| 11R22.5 | 16 | 146/143 | M | 8.25 | 14.5 | 1054 | 279 | 3000/2725 | 830/830 |
| 11R22.5 | 18 | 149/146 | L | 8.25 | 14.5 | 1054 | 279 | 3250/3000 | 930/930 |
